<!-- This file contains the mapping of keys (gamepad, remote, and keyboard) to actions within XBMC -->
<!-- The <global> section is a fall through - they will only be used if the button is not -->
<!-- used in the current window's section. Note that there is only handling -->
<!-- for a single action per button at this stage. -->
<!-- For joystick/gamepad configuration under linux/win32, see below as it differs from xbox -->
<!-- gamepads. -->
<!-- The format is: -->
<!-- <device> -->
<!-- <button>action</button> -->
<!-- </device> -->
<!-- To map keys from other remotes using the RCA protocol, you may add <universalremote> blocks -->
<!-- In this case, the tags used are <obc#> where # is the original button code (OBC) of the key -->
<!-- You set it up by adding a <universalremote> block to the window or <global> section: -->
<!-- <universalremote> -->
<!-- <obc45>Stop</obc45> -->
<!-- </universalremote> -->
<!-- Note that the action can be a built-in function. -->
<!-- eg <B>XBMC.ActivateWindow(MyMusic)</B> -->
<!-- would automatically go to My Music on the press of the B button. -->
<!-- Joysticks / Gamepads: -->
<!-- See the sample PS3 controller configuration below for the format. -->
<!-- -->
<!-- Joystick Name: -->
<!-- Do 'cat /proc/bus/input/devices' or see your xbmc log file to find the names of -->
<!-- detected joysticks. The name used in the configuration should match the detected name. -->
<!-- -->
<!-- Button Ids: -->
<!-- 'id' is the button ID used by SDL. Joystick button ids of connected joysticks appear -->
<!-- in xbmc.log when they are pressed. Use your log to map custom buttons to actions. -->
<!-- -->
<!-- Axis Ids / Analog Controls -->
<!-- Coming soon. -->
<keymap>
<global>
<remote>
<play>Play</play>
<pause>Pause</pause>
<stop>Stop</stop>
<forward>FastForward</forward>
<reverse>Rewind</reverse>
<left>Left</left>
<right>Right</right>
<up>Up</up>
<down>Down</down>
<select>Select</select>
<enter>FullScreen</enter>
<pageplus>PageUp</pageplus>
<pageminus>PageDown</pageminus>
<back>Back</back>
<menu>ContextMenu</menu>
<title>ContextMenu</title>
<info>Info</info>
<skipplus>SkipNext</skipplus>
<skipminus>SkipPrevious</skipminus>
<display>FullScreen</display>
<start>PreviousMenu</start>
<record>Screenshot</record>
<volumeplus>VolumeUp</volumeplus>
<volumeminus>VolumeDown</volumeminus>
<mute>Mute</mute>
<power>XBMC.ShutDown()</power>
<myvideo>XBMC.ActivateWindow(MyVideos)</myvideo>
<mymusic>XBMC.ActivateWindow(MyMusic)</mymusic>
<mypictures>XBMC.ActivateWindow(MyPictures)</mypictures>
<mytv>XBMC.ActivateWindow(MyPVR)</mytv>
<guide>XBMC.ActivateWindowAndFocus(MyPVR, 31,0, 10,0)</guide>
<livetv>XBMC.ActivateWindowAndFocus(MyPVR, 32,0, 11,0)</livetv>
<liveradio>XBMC.ActivateWindowAndFocus(MyPVR, 33,0, 12,0)</liveradio>
<recordedtv>XBMC.ActivateWindowAndFocus(MyPVR, 34,0, 13,0)</recordedtv>
<epgsearch>XBMC.ActivateWindow(PVROSDChannels)</epgsearch>
<yellow>XBMC.ActivateWindow(MyMusic)</yellow>
<blue>XBMC.ActivateWindow(MyPictures)</blue>
<zero>Number0</zero>
<one>Number1</one>
<two>JumpSMS2</two>
<three>JumpSMS3</three>
<four>JumpSMS4</four>
<five>JumpSMS5</five>
<six>JumpSMS6</six>
<seven>JumpSMS7</seven>
<eight>JumpSMS8</eight>
<nine>JumpSMS9</nine>
<red>ToggleWatched</red>
<green>RunScript(script.xbmc.subtitles)</green>
</remote>
</global>
<Home>
<remote>
<info>XBMC.ActivateWindow(SystemInfo)</info>
<clear>XBMC.ActivateWindow(Weather)</clear>
<hash>XBMC.ActivateWindow(Settings)</hash>
</remote>
</Home>
<MyTV>
<remote>
<clear>Delete</clear>
<menu>XBMC.ActivateWindow(PVROSDChannels)</menu>
</remote>
</MyTV>
<MyFiles>
<remote>
<clear>Delete</clear>
<zero>Highlight</zero>
<star>Move</star>
<hash>Rename</hash>
</remote>
</MyFiles>
<MyMusicPlaylist>
<remote>
<clear>Delete</clear>
<zero>Delete</zero>
</remote>
</MyMusicPlaylist>
<MyMusicPlaylistEditor>
<remote>
<zero>Queue</zero>
</remote>
</MyMusicPlaylistEditor>
<MyMusicFiles>
<remote>
<zero>Queue</zero>
<star>Queue</star>
</remote>
</MyMusicFiles>
<MyMusicLibrary>
<remote>
<zero>Queue</zero>
<star>Queue</star>
</remote>
</MyMusicLibrary>
<FullscreenVideo>
<remote>
<zero>Number0</zero>
<one>Number1</one>
<two>Number2</two>
<three>Number3</three>
<four>Number4</four>
<five>Number5</five>
<six>Number6</six>
<seven>Number7</seven>
<eight>Number8</eight>
<nine>Number9</nine>
<left>StepBack</left>
<right>StepForward</right>
<up>BigStepForward</up>
<down>BigStepBack</down>
<back>SmallStepBack</back>
<menu>OSD</menu>
<start>OSD</start>
<select>play</select>
<title>CodecInfo</title>
<info>Info</info>
<guide>XBMC.ActivateWindow(PVROSDGuide)</guide>
<teletext>XBMC.ActivateWindow(Teletext)</teletext>
<volumeminus>NextSubtitle</volumeminus>
<star>NextSubtitle</star>
<volumeplus>AudioNextLanguage</volumeplus>
<playlist>Playlist</playlist>
<language>Language</language>
<hash>AudioNextLanguage</hash>
</remote>
</FullscreenVideo>
<VideoTimeSeek>
<remote>
<select>Select</select>
<enter>Select</enter>
</remote>
</VideoTimeSeek>
<FullscreenInfo>
<remote>
<title>CodecInfo</title>
<info>Back</info>
<menu>OSD</menu>
</remote>
</FullscreenInfo>
<PlayerControls>
<remote>
<menu>Back</menu>
</remote>
</PlayerControls>
<Visualisation>
<remote>
<left>PreviousPreset</left>
<right>NextPreset</right>
<up>IncreaseRating</up>
<down>DecreaseRating</down>
<back>LockPreset</back>
<title>CodecInfo</title>
<select>XBMC.ActivateWindow(VisualisationPresetList)</select>
<menu>XBMC.ActivateWindow(MusicOSD)</menu>
<start>XBMC.ActivateWindow(MusicOSD)</start>
<info>Info</info>
<guide>XBMC.ActivateWindow(PVROSDGuide)</guide>
<playlist>XBMC.ActivateWindow(PVROSDChannels)</playlist>
</remote>
</Visualisation>
<MusicOSD>
<remote>
<menu>Back</menu>
<title>Info</title>
<info>CodecInfo</info>
</remote>
</MusicOSD>
<VisualisationSettings>
<remote>
<menu>Back</menu>
</remote>
</VisualisationSettings>
<VisualisationPresetList>
<remote>
<menu>Back</menu>
</remote>
</VisualisationPresetList>
<SlideShow>
<remote>
<zero>ZoomNormal</zero>
<one>ZoomLevel1</one>
<two>ZoomLevel2</two>
<three>ZoomLevel3</three>
<four>ZoomLevel4</four>
<five>ZoomLevel5</five>
<six>ZoomLevel6</six>
<seven>ZoomLevel7</seven>
<eight>ZoomLevel8</eight>
<nine>ZoomLevel9</nine>
<info>CodecInfo</info>
<skipplus>NextPicture</skipplus>
<skipminus>PreviousPicture</skipminus>
<title>Info</title>
<select>Rotate</select>
</remote>
</SlideShow>
<ScreenCalibration>
<remote>
<select>NextCalibration</select>
<zero>ResetCalibration</zero>
<display>NextResolution</display>
<xbox>NextResolution</xbox>
</remote>
</ScreenCalibration>
<GUICalibration>
<remote>
<select>NextCalibration</select>
<zero>ResetCalibration</zero>
</remote>
</GUICalibration>
<VideoOSD>
<remote>
<menu>Back</menu>
<start>Back</start>
</remote>
</VideoOSD>
<VideoMenu>
<remote>
<menu>OSD</menu>
<info>Info</info>
<title>CodecInfo</title>
<zero>Number0</zero>
<one>Number1</one>
<two>Number2</two>
<three>Number3</three>
<four>Number4</four>
<five>Number5</five>
<six>Number6</six>
<seven>Number7</seven>
<eight>Number8</eight>
<nine>Number9</nine>
<play>Select</play>
<togglewatched>ToggleWatched</togglewatched>
</remote>
</VideoMenu>
<OSDVideoSettings>
<remote>
<menu>Back</menu>
<start>Back</start>
</remote>
</OSDVideoSettings>
<OSDAudioSettings>
<remote>
<menu>Back</menu>
<start>Back</start>
</remote>
</OSDAudioSettings>
<VideoBookmarks>
<remote>
<menu>Back</menu>
<start>Back</start>
<zero>Delete</zero>
</remote>
</VideoBookmarks>
<MyVideoLibrary>
<remote>
<zero>Queue</zero>
<clear>Delete</clear>
</remote>
</MyVideoLibrary>
<MyVideoFiles>
<remote>
<zero>Queue</zero>
<star>Queue</star>
</remote>
</MyVideoFiles>
<MyVideoPlaylist>
<remote>
<clear>Delete</clear>
<zero>Delete</zero>
</remote>
</MyVideoPlaylist>
<VirtualKeyboard>
<remote>
<back>BackSpace</back>
<star>Shift</star>
<hash>Symbols</hash>
<zero>Number0</zero>
<one>Number1</one>
<two>Number2</two>
<three>Number3</three>
<four>Number4</four>
<five>Number5</five>
<six>Number6</six>
<seven>Number7</seven>
<eight>Number8</eight>
<nine>Number9</nine>
<enter>Enter</enter>
<pageminus>CursorLeft</pageminus>
<pageplus>CursorRight</pageplus>
</remote>
</VirtualKeyboard>
<ContextMenu>
<remote>
<title>Back</title>
</remote>
</ContextMenu>
<Scripts>
<remote>
<info>info</info>
</remote>
</Scripts>
<NumericInput>
<remote>
<zero>Number0</zero>
<one>Number1</one>
<two>Number2</two>
<three>Number3</three>
<four>Number4</four>
<five>Number5</five>
<six>Number6</six>
<seven>Number7</seven>
<eight>Number8</eight>
<nine>Number9</nine>
<enter>Enter</enter>
<back>BackSpace</back>
</remote>
</NumericInput>
<Weather>
<remote>
<back>PreviousMenu</back>
</remote>
</Weather>
<TV>
<remote>
<red>Red</red>
<yellow>Yellow</yellow>
<blue>Blue</blue>
<menu>XBMC.ActivateWindow(PVROSDChannels)</menu>
</remote>
</TV>
<Settings>
<remote>
<back>PreviousMenu</back>
</remote>
</Settings>
<AddonBrowser>
<remote>
</remote>
</AddonBrowser>
<AddonInformation>
<remote>
<back>Close</back>
</remote>
</AddonInformation>
<AddonSettings>
<remote>
<back>Close</back>
</remote>
</AddonSettings>
<TextViewer>
<remote>
<back>Close</back>
</remote>
</TextViewer>
<MyPicturesSettings>
<remote>
<back>PreviousMenu</back>
</remote>
</MyPicturesSettings>
<MyProgramsSettings>
<remote>
<back>PreviousMenu</back>
</remote>
</MyProgramsSettings>
<MyWeatherSettings>
<remote>
<back>PreviousMenu</back>
</remote>
</MyWeatherSettings>
<MyMusicSettings>
<remote>
<back>PreviousMenu</back>
</remote>
</MyMusicSettings>
<SystemSettings>
<remote>
<back>PreviousMenu</back>
</remote>
</SystemSettings>
<MyVideosSettings>
<remote>
<back>PreviousMenu</back>
</remote>
</MyVideosSettings>
<NetworkSettings>
<remote>
<back>PreviousMenu</back>
</remote>
</NetworkSettings>
<AppearanceSettings>
<remote>
<back>PreviousMenu</back>
</remote>
</AppearanceSettings>
<Profiles>
<remote>
<back>PreviousMenu</back>
</remote>
</Profiles>
<systeminfo>
<remote>
<back>PreviousMenu</back>
</remote>
</systeminfo>
<shutdownmenu>
<remote>
<back>PreviousMenu</back>
</remote>
</shutdownmenu>
<submenu>
<remote>
<back>PreviousMenu</back>
</remote>
</submenu>
<MusicInformation>
<remote>
<info>Back</info>
</remote>
</MusicInformation>
<MovieInformation>
<remote>
<info>Back</info>
</remote>
</MovieInformation>
<LockSettings>
<remote>
<menu>Back</menu>
</remote>
</LockSettings>
<ProfileSettings>
<remote>
<menu>Back</menu>
</remote>
</ProfileSettings>
<PictureInfo>
<remote>
<skipplus>NextPicture</skipplus>
<skipminus>PreviousPicture</skipminus>
<info>Back</info>
</remote>
</PictureInfo>
<Teletext>
<remote>
<zero>number0</zero>
<one>number1</one>
<two>number2</two>
<three>number3</three>
<four>number4</four>
<five>number5</five>
<six>number6</six>
<seven>number7</seven>
<eight>number8</eight>
<nine>number9</nine>
<red>Red</red>
<yellow>Yellow</yellow>
<blue>Blue</blue>
<info>Info</info>
<menu>Back</menu>
<start>Back</start>
<teletext>Back</teletext>
</remote>
</Teletext>
<Favourites>
<remote>
<back>Close</back>
</remote>
</Favourites>
<PVROSDChannels>
<remote>
<back>Close</back>
<menu>Close</menu>
<start>Close</start>
<playlist>Close</playlist>
</remote>
</PVROSDChannels>
<PVROSDGuide>
<remote>
<back>Close</back>
<menu>Close</menu>
<start>Close</start>
<guide>Close</guide>
</remote>
</PVROSDGuide>
<PVROSDDirector>
<remote>
<back>Close</back>
<menu>Close</menu>
</remote>
</PVROSDDirector>
<PVROSDCutter>
<remote>
<back>Close</back>
<menu>Close</menu>
</remote>
</PVROSDCutter>
<MyTVSettings>
<remote>
<back>PreviousMenu</back>
<menu>XBMC.ActivateWindow(PVROSDChannels)</menu>
<info>XBMC.ActivateWindow(PVROSDChannels)</info>
</remote>
</MyTVSettings>
<AddonSettings>
<remote>
<clear>Delete</clear>
</remote>
</AddonSettings>
</keymap>
...
