SMI NVME SSD flash id v0.272a by Ochkin Vadim
OS: 10.0 build 20348
0: (KINGSTON SKC600512G
1: (HGST HUS722T2TALA604
2: (KINGSTON SNVS500G
3: (KINGSTON SNVS1000G
Please select drive number:3
Drive : 3(NVME)
Scsi : 2
IOCtl: NVME_OF failed 0x45d!
Driver : W10
Model : KINGSTON SNVS1000G
Fw : S8I40100
HMB : 65536 - 65536 KB (Enabled, 64 M)
Size : 953869 MB [1000.2 GB]
LBA Size : 512
Controller: [SM2263XT] bufferless
Bank00: 0x98,0x3e,0x98,0x3,0x76,0xe4,0x0,0x0 - Toshiba 112L BiCS5 TLC 16k 512Gb/CE 512Gb/die 2Plane/die
Bank01: 0x98,0x3e,0x98,0x3,0x76,0xe4,0x0,0x0 - Toshiba 112L BiCS5 TLC 16k 512Gb/CE 512Gb/die 2Plane/die
Bank02: 0x98,0x3e,0x98,0x3,0x76,0xe4,0x0,0x0 - Toshiba 112L BiCS5 TLC 16k 512Gb/CE 512Gb/die 2Plane/die
Bank03: 0x98,0x3e,0x98,0x3,0x76,0xe4,0x0,0x0 - Toshiba 112L BiCS5 TLC 16k 512Gb/CE 512Gb/die 2Plane/die
Bank04: 0x98,0x3e,0x98,0x3,0x76,0xe4,0x0,0x0 - Toshiba 112L BiCS5 TLC 16k 512Gb/CE 512Gb/die 2Plane/die
Bank05: 0x98,0x3e,0x98,0x3,0x76,0xe4,0x0,0x0 - Toshiba 112L BiCS5 TLC 16k 512Gb/CE 512Gb/die 2Plane/die
Bank06: 0x98,0x3e,0x98,0x3,0x76,0xe4,0x0,0x0 - Toshiba 112L BiCS5 TLC 16k 512Gb/CE 512Gb/die 2Plane/die
Bank07: 0x98,0x3e,0x98,0x3,0x76,0xe4,0x0,0x0 - Toshiba 112L BiCS5 TLC 16k 512Gb/CE 512Gb/die 2Plane/die
Bank08: 0x98,0x3e,0x98,0x3,0x76,0xe4,0x0,0x0 - Toshiba 112L BiCS5 TLC 16k 512Gb/CE 512Gb/die 2Plane/die
Bank09: 0x98,0x3e,0x98,0x3,0x76,0xe4,0x0,0x0 - Toshiba 112L BiCS5 TLC 16k 512Gb/CE 512Gb/die 2Plane/die
Bank10: 0x98,0x3e,0x98,0x3,0x76,0xe4,0x0,0x0 - Toshiba 112L BiCS5 TLC 16k 512Gb/CE 512Gb/die 2Plane/die
Bank11: 0x98,0x3e,0x98,0x3,0x76,0xe4,0x0,0x0 - Toshiba 112L BiCS5 TLC 16k 512Gb/CE 512Gb/die 2Plane/die
Bank12: 0x98,0x3e,0x98,0x3,0x76,0xe4,0x0,0x0 - Toshiba 112L BiCS5 TLC 16k 512Gb/CE 512Gb/die 2Plane/die
Bank13: 0x98,0x3e,0x98,0x3,0x76,0xe4,0x0,0x0 - Toshiba 112L BiCS5 TLC 16k 512Gb/CE 512Gb/die 2Plane/die
Bank14: 0x98,0x3e,0x98,0x3,0x76,0xe4,0x0,0x0 - Toshiba 112L BiCS5 TLC 16k 512Gb/CE 512Gb/die 2Plane/die
Bank15: 0x98,0x3e,0x98,0x3,0x76,0xe4,0x0,0x0 - Toshiba 112L BiCS5 TLC 16k 512Gb/CE 512Gb/die 2Plane/die
Channel: 4
CE : 4
Plane : 2
Die/Ce : 1
Ch map : 0x0F
CE map : 0x0F
Bit Per Cell : (TLC)
Inter. : 4
Pages/Block : 1344(448)
First Fblock : 1
Total Fblock : 1662
Total Hblock : 0
Fblock Per Ce : 1662
Fblock Per Die: 1662
Original Spare Block Count : 135
Vendor Marked Bad Block : 0
Bad Block From Pretest : 15
IOCtl: NVME_W10_GetLog 0x45d!
